Pouch&bag producing machine

TF-600BDLL is a multi-functional pouch making machine with its features of making three sides sealing .standing with extra films(double lines),zipper locked pouch(double lines).folded standing pouch and huge size four side sealing pouch with extra film .it is consist of PLC with servo motor infeeding units.

TF-600BDLL is a multi-functional pouch making machine with its features of making three sides sealing .standing with extra films(double lines),zipper locked pouch(double lines).folded standing pouch and huge size four side sealing pouch with extra film .it is consist of PLC with servo motor infeeding units.

Model

TF-600BDLL

Film

All kinds of laminated film

Roll size

Max width:1240mm Max diameter:600mm

Production efficiency

160 parts/min (actual operation speed depends on material and bag shape

Size of pouch

Width:600mm; length:50-500mm(Skip-infeeding will be adopted when over)

Air pressure

0.6Mpa

Cooling water

15L/min

Total power

65Kw

Overall dimensions

14500mm×1580mm×1800mm(L×W×H)

 Weight

6500Kg
